Luogo di origine: | La Cina |
Marca: | Small Boss |
Certificazione: | SGS, FDA, ISO9001 |
Numero di modello: | PE08 |
Quantità di ordine minimo: | 5cbm |
---|---|
Prezzo: | discuss personally |
Imballaggi particolari: | Cartone |
Tempi di consegna: | come vostro qty di requisito |
Termini di pagamento: | L/C, T/T |
Capacità di alimentazione: | 250M3 AL GIORNO |
Dimensione: | 5*10mm | Materiale: | ANCHE |
---|---|---|---|
Colore: | Bianco | Usando: | Trattamento delle acque |
Pacchetto: | Borsa tessuta | Porto: | SHANGHAI O NINGBO |
Evidenziare: | Il carro armato aerobico Kaldnes il corpo filtrante,Corpo filtrante di Kaldnes delle ANCHE,Corpo filtrante di Kaldnes di tecnologia di MBBR |
product introduction
MBBR filter media is a novel biologically active carrier, it adopts scientific formula, depending on the nature of water, blending a variety of beneficial microorganisms grow quickly attached trace elements in polymer materials, through a special process modification, constructed, with more than large surface area, hydrophilic, high biological activity, biofilm fast, good effect, good impact resistance.
The core of the MBBR technology are the biofilm carriers.
They are designed to provide a large protected surface area for the biofilm and optimal conditions for the bacteria culturea when the carriers are suspended in water.
Small Boss has developed several types of carriers with different shape, size and surface area. This gives us the flexibility to use the best suitable carrier depending on wastewater characteristics, pretreatment, discharge standards and available volumes. Currently we have ten different types of carriers.
Biological treatment and filtration occur simultaneously within the system as two separate media types are contained within the same treatment cell.
Wastewater first flows through a dynamic MBBR media layer which provides a large surface area and an open void for biofilm growth and treatment.
Flow then passes through the media layer, which provides additional fixed film treatment and filtration as the water flows up through the fixed bed.
Specifications:
Model | Size(mm) | Specific Surface Area(m2/m3) | Bio-film formation Duration (days) |
Nitrification Efficiency | Preferential Temperature (ºC) | Services life(years) | Number of unites per m3 |
PE08 | Φ5×10 | >3500 | 5-15 | 500-1400 | <65 | ≥15 | >1,540,000 |
